Amphenol PCD Shenzhen

HVCOCF6ATR8SF970L0000

part number:

HVCOCF6ATR8SF970L0000

datasheet:

view / download

specifications:

connection:

crimp

housing:

plastic

IP Rating:

IP44

market:

electric vehicle

positions:

product type:

power connector

shape:

circular

voltage:

1000V

Rated Voltage: 1000V AC (DC+& DC-), 480V DC (L1,L2, L3 & N)

Rated Current: 200A (DC+ & DC-：70MM2 Cable), 32A (L1,L2, L3 & N: 6mm2 Cable)

Mating Cycles >10,000 Cycles

DESCRIPTION

IEC COMBO RECEPTACLE FOR VEHICLE, AC32A+DC200A, 3 PHASE
