Amphenol PCD Shenzhen

HVCOIMBSCR6PS502LXXXX

part number:

HVCOIMBSCR6PS502LXXXX

datasheet:

view / download

specifications:

connection:

crimp

housing:

plastic

IP Rating:

IP55

market:

electric vehicle

positions:

product type:

power connector

shape:

voltage:

250V

Rated Voltage: 250V AC (LI, N & PE), 30V DC (PP & CP)

Rated Current: 20A Max (LI & N: 2.5MM2 Cable), 2A Max (PP & CP)

Mating Cycles >10,000 Cycles

DESCRIPTION

IEC CHARGING COUPLER 20A, SINGLE PHASE, CABLE ASSEMBLY-POTTING
