HVSL364014A106I
part number:HVSL364014A106I
datasheet:
  view / download
specifications:
connection: crimp
housing: plastic
IP Rating: IP67 IP6K9K
market: electric vehicle
positions: 4
product type: power connector
shape: rectangular
voltage: 1000V
Wire Range: 6mm2 Shielded Wire
Rated Current: 46A Max
DESCRIPTION
IN-LINE RECEPTACLE, 4+2 PIN, ALTERNATE POSITION A, HVIL, 6MM2, INDIVIDUALLY SHIELDED WIRE
