HEV070AF2P4SF
part number:
HEV070AF2P4SF
datasheet:
  view / download
specifications:
connection:
crimp
housing:
metal
IP Rating:
market:
electric vehicle
positions:
6
product type:
power connector signal connector
shape:
rectangular
voltage:
Rated Voltage: Power: 600V DC, Signal: 12 To 24 V
Rated Current: Power: 70A, Signal: 13A
Wire Range: Power: 16MM2, Signal: 2.5 MM2
BATTERY SWAP MODELES 70A RECEPTACLE,  2 PIN POWER  + 4 PIN SIGNAL
