HVSLS800062XXXX
part number:
HVSLS800062XXXX
datasheet:
  view / download
specifications:
connection:
crimp
current:
150A 180A 120A
housing:
metal
IP Rating:
IP67 IP6K9K
market:
electric vehicle
positions:
2
product type:
power connector
voltage:
1000V
DESCRIPTION
STRAIGHT PLUG, 2 PIN, 180A MAX, ALTERNATE POSITION A/B, WITH HVIL, 50MM2 CABL

RATED CURRENT:
180A@50MM2 SHIELDED CABLE
150A@35MM2 SHIELDED CABLE
120A@25MM2 SHIELDED CABLE
